Max. Pressure 35 ~ 140 Bar ( 500 ~ 2,000 PSI )
Max. Flow Rate 12 ~ 25 LPM ( 3 ~ 6.8 GPM )
Coolant Type Water & Oil

■ Features

High quality gear pump.
Use disposable filter bag, it's efficient, time saving,
easy and safe.
Pressure adjustment conform with ergonomics.
Built-in the pressure is too low or too high alarm.
With tri-color signal light tower, can warning
the status.
With emergency stop switch.
Built-in filter warning and stop system.

■    CONCEALED DESIGN

Optional concealed design u of SP series specially for saving floor space which can be installed beneath
bar feeder.

■ Specifications

Models SP 1000 SP 2000 SE 500 SE 1000 SE 1500
Coolant Type Oil Oil / Water
Max. Pressure 70 Bar*1
( 1,000 PSI )
140 Bar*1
( 2,000 PSI )
35 Bar
( 500 PSI )
70 Bar
( 1,000 PSI )
100 Bar
( 1,500 PSI )
Max. Flow Rate 12 LPM*1
( 3 GPM )
19 LPM*1
( 5 GPM )
25 LPM
( 6.6 GPM )
25 LPM
( 6.6 GPM )
24 LPM
( 6.3 GPM )
Pressure Adjustment Manual
High Pressure Pump Gear Pump
Motor 2.2 kW ( 3 HP ) 5.5 kW ( 7.5 HP ) 2.2 kW ( 3 HP ) 5.5 kW ( 7.5 HP ) 7.5 kW ( 10 HP )
Filtration System
Min. & Max. Pressure Detection Yes
Filter Replacement Detection Yes
Tri-Color Signal Light Tower Yes
Number of Ports 4 / 8
Voltage, Frequency 3 Phase 220 V ( ±10 % ), 60 Hz
Rated Current 10 A 25 A 10 A 25 A 30 A
Option
/
Dimensions L x W x H 85 x 47 x 108.5 cm 92 x 47 x 108.5 cm

*1 Was tested with temperature : 40°C / viscosity : 46 CST oil in 220V, 60Hz.

Smart Inverter ( Ethernet + AVP control )

Concealed Design

Specifications are subject to change without notice.
